Multi-Process Welding Machine
The TELWIN Infinity 200 delivers stable, precise welding up to 200A, providing reliable results with a wide range of electrodes, including rutile, basic, stainless steel, and cast iron up to 4 mm thickness. Its compact, lightweight design allows easy portability and maneuverability without sacrificing power. With advanced arc control technology, it maintains smooth, consistent welding even under fluctuating mains voltage, producing cleaner welds with minimal spatter.
On this model of MMA electrode and TIG welding inverter welder, the Arc Force, Anti-Stick, and Hot Start devices ensure smooth, safe, and efficient welding even under demanding conditions. The Arc Force facilitates precise transfer of molten material from the electrode to the workpiece, preventing interruptions. Anti-Stick automatically switches off the welding generator when the electrode sticks, allowing safe manual removal. Hot Start provides a surge current at each restart, enabling fast ignition of the electric arc. Browse more choices within our [Welding Machines] range.
Types of Welding:
This versatile welding machine supports multiple methods:
MMA: Coated electrode welding, ideal for general industrial use or tasks not requiring aesthetic precision. Simple yet reliable for professional and non-professional environments.
TIG: Low-voltage welding delivering precise, clean arcs. TIG welding is highly resistant and visually clean, perfect for visible elements and processes requiring precision.
• 200A DC Welding Output: Delivers strong, stable, and consistent performance for professional welding applications.
• Electrode Range 1.6–4 mm: Supports diverse welding tasks from light repairs to heavy-duty fabrication.
• MMA & TIG Compatibility: Flexible operation for electrode welding and scratch TIG applications.
• Advanced Arc Control Technology: Hot Start for easy ignition, Arc Force for stabilized welding, and Anti-Stick prevents electrode sticking.
• Excellent Arc Stability: Maintains smooth and continuous welding even under fluctuating mains voltage.
• Generator Compatible: Operates reliably with motor generators at 230V ±15%, ideal for field use.
• Multi-Level Protection System: Includes thermal cut-off, overvoltage, undervoltage, and overcurrent protection for safe operation.
• Energy-Efficient Inverter Technology: Reduces power consumption while maximizing welding output and efficiency.
• Compact & Lightweight Design: Only 3.7 kg for easy portability across workshops and job sites.
• Italian Manufacturing Quality: Built with premium components for long-term reliability, professional-grade performance, and durability.
• User-Friendly Operation: Simple controls allow quick adjustments for both beginners and experienced welders.
Welding machine
Electrode holder 300A
Ground clamp 250A
Cable 1.8 m
User manual
| Model | Infinity 200 |
|---|---|
| Code | 816129 |
| Input Voltage | 230 V (Single Phase) |
| Frequency | 50 / 60 Hz |
| Current Range DC | 10 – 200 A |
| Max Current (EN60974-1) | 180 A @ 20% |
| Current @ 35% | 130 A |
| Current @ 60% | 110 A |
| No Load Voltage | 82 V |
| Max Absorbed Current | 36 A |
| Absorbed Power Max | 5.6 kW |
| Absorbed Power @ 60% | 3.1 kW |
| Generator Min Power | 8 kW |
| Usable Electrodes | 1.6 – 4 mm |
| Efficiency | 86% |
| Protection Class | IP23 |
| Insulation Class | F |
| Dimensions | 304 × 138 × 213 mm |
| Weight | 3.7 kg |
| Country of Origin | Italy |
