Pneumatic Poison Oil Pump
Warranty
6 Months
The SAMOA 535510 from the advanced PM35 series is a formidable double-acting pneumatic pump built to conquer challenging oil distribution networks. When your facility requires piping engine oil or transmission fluids over vast distances or through multiple hose reels, this unit utilizes a highly potent 5:1 pressure ratio to generate an impressive maximum fluid pressure of 60 bar (870 psi). It features a perfectly calibrated 925 mm pump tube with a built-in bung adapter, allowing it to drop flawlessly into standard 205-liter (55-gallon) drums for immediate deployment.
At the core of this powerhouse is an oversized 80 mm air motor designed for optimized, continuous cycling. Operating smoothly within an air pressure range of 2 to 12 bar, it achieves a rapid maximum free flow of 30 liters per minute (8 gal/min) to eliminate wait times in busy service centers. Durability is fully guaranteed through a rugged carbon steel tube paired with premium wetted components like hard chromed steel, aluminum, and NBR seals. Despite weighing 8 kg and delivering extreme performance, it manages to maintain a highly controlled, quiet sound level of just 80 dB.
• High-Pressure 5:1 Ratio: Generates up to 60 bar to efficiently push heavy oil through long pipelines and hose reels.
• High-Volume Transfer (30 L/min): Ensures fast and efficient fluid dispensing for high-demand workshop operations.
• Double-Acting Pump Operation: Provides smooth, continuous fluid flow using an optimized 80 mm air motor.
• Multi-Fluid Compatibility: Designed for engine oils, ATF, and similar lubricants for versatile workshop use.
• Direct Drum Integration (925 mm Tube): Secure mounting into standard 205L (55-gallon) drums for stable operation.
• Reliable Ball Check Inlet System: Maintains pump priming and ensures consistent, efficient fluid intake.
• Built-In Relief Port: Ready for optional pressure relief valve installation to enhance system safety.
• Premium Industrial Materials: Carbon steel tube, hard chromed steel components, and NBR seals ensure durability and chemical resistance.
• Compact & Quiet Operation (8 kg / 80 dB): Lightweight design with low noise level for comfortable indoor use.
• Wide Operating Pressure Range (2–12 bar): Flexible performance across different air supply systems.
• Stable Fluid Delivery: Minimizes pulsation for smooth and controlled output during operation.
| Model | 535510 |
|---|---|
| Brand | SAMOA (PM35 Series) |
| Compatible Fluids | Oil, Transmission Fluid |
| Pump Mounting | 205 L (55 gal) Drum Bung Mounted |
| Pressure Ratio | 5-1 |
| Air Pressure Operating Range | 2 - 12 bar (29 - 174 psi) |
| Air Consumption | 350 NL/min (12.4 scfm) |
| Maximum Outlet Pressure | 60 bar (870 psi) |
| Air Motor Effective Diameter | 80 mm (3.15") |
| Air Motor Stroke | 80 mm (3.2") |
| Delivery Per Cycle | 12 L (3.2 gal) |
| Cycles Per Minute (Approx.) | 80 Cycles |
| Delivery | 12 L/min (3.2 gal/min) |
| Maximum Free Flow Delivery | 30 L/min (8 gal/min) |
| Air Inlet | 3/8" BSP (F) |
| Fluid Inlet | 1 1/2" BSP (F) |
| Fluid Inlet Type | Ball Check |
| Fluid Outlet | 1/2" BSP (F) |
| Wetted Materials | Hard Chromed Steel, Steel, Polyurethane, NBR, Aluminium |
| Pump Tube Material | Carbon Steel |
| Sound Level | 80 dB |
| Pump Tube Height | 925 mm (36.4") |
| Total Height | 1194 mm (47") |
| Weight | Approx. 8 Kg (17.6 lb) |
| Country of Origin | Spain |
