PIUSI Electric Diesel Transfer Pump, 500W, 72 L/min, Made in Italy - F00736020

Piusi Panther 72 Diesel Pump

For stationary refueling stations and large-scale industrial depots, minimizing vehicle downtime is absolutely critical. The PIUSI Panther 72 Electric Diesel Transfer Pump (F00736020) addresses this exact requirement by harnessing a formidable 500W AC motor. Designed, engineered, and fully manufactured in Italy, this self-priming rotary vane unit operates seamlessly on a standard 220V power supply. By achieving an accelerated internal rotation of 3400 RPM, the intense rotational energy translates directly into a high-velocity dispensing output of 72 L/min (19 GPM), drastically shortening the refueling window.

Rigid plumbing integration and absolute physical durability define the architectural layout of the Panther 72. Encased within a highly resilient cast iron body weighing exactly 8 kg, the internal pumping mechanism operates flawlessly thanks to a precision-ground steel shaft, advanced technopolymer vanes, and a high-density sintered steel rotor. Supplied straight out of the box with completely removable 1" companion flanges, stationary pipe installation is exceptionally fast and flexible. To guarantee operational safety, a built-in mechanical bypass valve instantly redirects the diesel flow whenever dispensing nozzles are closed, while a pre-installed mesh strainer actively captures dirt and rust particles before they can breach the primary pumping chamber.

Key Features & Benefits:

• High-Velocity Output: Delivers a massive output of 72 liters per minute (19 GPM), optimizing stationary depot logistics by slashing the time required to fill massive commercial fuel tanks.

• Powerful AC Motor: Powered by a highly robust 500W, 220V electric motor drawing a maximum current of 3.9 Amperes, perfectly suited for constant-power environments and rigid facilities.

• Accelerated 3400 RPM Speed: High-speed internal rotation ensures highly consistent, rapid self-priming capabilities and eliminates pressure drops over extended hydraulic delivery lines.

• Sintered Steel Rotor: The metallurgy core utilizes high-density sintered steel to provide maximum sheer strength and actively resist internal structural wear over thousands of operational hours.

• Technopolymer Vanes: Heavy-duty structural resin blades offer extremely low friction coefficients, ensuring fluid moves smoothly and quietly without grinding down the internal housing.

• Precision Steel Shaft: A meticulously balanced steel motor shaft guarantees exact internal centering, heavily suppressing operational vibration and reducing mechanical noise.

• Flange Connections Included: Packed standard with removable 1" companion flanges, facilitating rapid, secure pipe configurations and incredibly easy maintenance without dismantling plumbing.

• Mechanical Bypass Valve: A built-in safety circuit intelligently redirects internal fluid flow the exact second the fuel dispensing nozzle is closed, protecting hoses from bursting.

• Integrated Mesh Filter: Features a strategically placed mesh inlet strainer to trap coarse particles, dirt, and tank sediment before they can enter and score the pump chamber.

• Exceptional Suction Range: Capable of safely pulling diesel across a maximum horizontal intake run of 6 meters, and vertically up to 4 meters when configured with a non-return foot valve.
